8 Port Serial PCI Interface Card
In stock
Only 1 left
SKU
250008
Special Price €86.48 Regular Price €172.95
The RS-232 Golden I/O series, a line of Universal PCI Multi-port Serial Communications Board, is a 32-bit Plug-n-Play Bus card equipped with independent high-speed RS-232 (V24 standard serial interface). The Card attaches 1/2/4/8 independent DB9 or DB25 Rs-232 serial ports on your system for industrial communication and automation applications. It is compatible with both 3.3v or 5v and 32-bit or 64-bit PCI Bus, allowing this multi-port serial card to be installed in virtually any available PC system and compatible with all major operating systems. Users do not need to manually set jumpers to configure I/O addresses and IRQ locations, The system will search the device automatically eliminating any conflicts with other cards or devices. Â
- Fully compatible with PCI spec. ver. 2.2/2.1 standardÂ
- Supports both 64-bit &32-bit PCI Bus and 3.3v & 5v connector keys
- Expands 1/2/4/8 independent RS-232 serial ports in one single boardÂ
- High speed 16C650 compatible communication controller with SUNIX self-design single-chip hardware flow control to guarantee no data loss and the best technical supportÂ
- Each serial port has built-in 32-byte hardware FIFO
- Data transmission speeds up to 115.2 Kbps
- Certified by Microsoft WHQL, CE, FCC ClassB approvalÂ
- Support Microsoft Windows, DOS, Linus, and SCO Unic major operation systems.
| Model | RS-232 Universal PCI Communication Board |
| Mode of Operation | HandShaking RS-232 Full-Duplex |
| Controller | SUNIX 16C650 Compatible UART |
| Bus Interface | 64-bit & 32-bit PCI Bus / 3.3v & 5v Connector key |
| Number of Ports | 1/2/4/8 ports with DB9 or DB25 male type |
| Brackets | Standard 121mm, low profile 79.2mm |
| IRQ & IO Address | Assigned by BIOS / O.S. |
| FIFO | 32 byte hardware FIFO |
| Baud Rate | 75 - 115, 200bps |
| Data Bit | 5, 6, 7, 8 |
| Stop Bit | 1, 1.5, 2 |
| Parity | Even, Odd, None, Mark, Space |
| Flow Control | None, Xon/Xoff, Hardware |
| Regulatory Approvals | CE, FCC / Microsoft WHQL |
| Colour | n/a |
|---|---|
| Interface | Serial |
