Kingston Fury 8GB DDR5-5200 UDIMM Memory RAM

Fury 8GB DDR5-5200

CL40 288-Pin DIMM

Description

Kingston FURY KF552C40BB-8 is a 1G x 64-bit (8GB) DDR5-5200 CL40 SDRAM (Synchronous DRAM) 1Rx16, memory module, based on four 1G x 16-bit FBGA components per module. The module supports Intel® Extreme Memory Profiles (Intel XMP) 3.0. Each module has been tested to run at DDR5-5200 at a low latency timing of 40-40-40 at 1.25V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers.

Features

• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• Height 1.37” (34.9mm), w/heatsink

Specifications

• CL(IDD): 40 cycles
• Row Cycle Time (tRCmin): 48ns(min.)
• Refresh to Active / Refresh - Command Time (tRFCmin): 295ns(min.)
• Row Active Time (tRASmin): 32ns(min.)
• UL Rating: 94 V - 0
• Operating Temperature: 0^o C to +85^o C
• Storage Temperature: -55^o C to +100^o C
